... .... Uses
.. Integrated Penetration Approval System - provides a full approval mechanism starting with the proposal of placing a penetration, through sign-off by the specialist, to the final implementation. In order to safeguard the process, the Penetrations module comes with numerous control functions such as:
User Permissions - Each user working on a project receives permissions assigned by the project manager, preventing users working on the product model outside their expertise.
Standardization - Penetrations are defined in the catalog, assigned to pipe sizes and grouped into specs.
Approval Process - The process is database controlled and enforces all parties to do their job at specific times. A revision log is generated automatically.
Revision History - Penetrations may be changed after approval, which starts the approval process over again.


.. Penetrations--管道穿透配件
这全新的软件和ShipConstructor 的数据库相互配合,用户只要做好管道设计,然后软件便自动检查干扰,凡是管道需要穿透钢板的地方,软件自动找出标准的穿透配件以便利用户选择。系统也自动加强钢板厚度,把穿透部分的承受力加高。


...Brief
.. Penetrations lets the user easily implement spec driven piping penetrations in structure that are associated with their sizes.
Sleeves, Collars, and Doubler Plates - Adds sleeves, collars, and doubler plates to penetrations through structure for pipe.
Unique ID - User defined unique ID's for all penetrations

... .. .Desirable System
.. Pentium-3 CPU, 256MB RAM; Windows XP/NT/2000
